Range
| SIZE | Un (V DC) | In (A) | INDICATOR | POLES | REFERENCE |
|---|---|---|---|---|---|
| 10x38 | 1000V | 32A | 1P | 485150   |
|
| 2P | 485151 |
||||
| 1P | 485152 |
||||
| 2P | 485153 |
Technical data
| Rated current | 32A |
| Rated voltage | 690V AC | 1000V DC |
| Maximum power dissipation | 4W |
| Power dissipation per pole | 80% In 0,27W 100% In 0,43W |
| Pollution degree | 3 |
| Protection index * | IP20 |
| Rated insulation voltage | 6kV U imp |
| Ambient temperature of service | -40°C ... 70°C (with carrier operation) -50°C ... 80°C (without carrier operation) |
| Storage temperature | -50°C ... 80°C |
| * To obtain an IP20 rating with cable protection of Ø ≤4.5mm, use the special protection accessory. | |
Standards
IEC/EN 60269-1
IEC/EN 60269-2
UL4248-1 Fuse holders
UL4248-19 Photovoltaic fuse holders
UL486E Wiring terminals
CSA C22.2 Nº 4248-1 Fuse holder assemblies
CSA 22.2 Nº 65 Wire connectors
Dimensions
Weight 1P 57gr · 2P 114gr
Certifications
Accessories
Multipolar assembly
Standard system by DF Electric: 2 clips and 1 pin for each union between poles.
| REFERENCE | DESCRIPTION |
| 480005 | Pins for multipole assembly |
| 485050 | Handle ties for multipole assembly |
Identification by label
Open the label holder part with the fuse holder closed, put on the label and close it. Label measures: 11x9mm.
Special IP20 protection
The accessory mut be positioned in the wire entries, if it’s neccesary to achieve the IP20 degree of protection with thin wires.
| REFERENCE | DESCRIPTION |
| 485052 | Special IP20 protection accessory |
Phase separators accessory
The accessory increases the distance between phases in multipolar asemblies.
| REFERENCE | DESCRIPTION |
| 485053 | Phase Separator accessory |
Screws protection accessory
Protection accesory to avoid the screws manipulation and improve the protection degree.
| REFERENCE | DESCRIPTION |
| 485656 | Screws protection accessory |
Lock of the fuse holder
Systems to avoid the operation and connection when the fuse holder is open or closed.
| REFERENCE | DESCRIPTION |
| 485051 | Lock accessory |
Fusing Indicator replacement instructions
Compatible
 |
|
| 10x38 Cylindrical gPV fuse link | |
| U | 1000V DC |
| In | 1A...20A |
| Breaking capacity | 30kA |
Other sizes
 |
|
|
| NEW | ||
 |
 |
|
|---|---|---|
| U | 1100V DC | 1500V DC |
| IN | 50A | 100A |
| |
||
